TCS10K5 10 kΩ Thermistor (0.5x3mm) Sold in 5-packs


From: $97.00

Bulk Pricing (6 - 14): $95.00

Contact Factory for High Volume Pricing
Price adjustments will be reflected in the cart. For availability information please contact us. All prices are in US dollars and are subject to change without notice. Prices do not include shipping charges. An additional OEM discount applies on orders over 14 pieces. Contact factory for pricing. If ordering from or shipping to Australia, China, Hong Kong or Israel please contact your distributor.

Precision temperature control starts with a precision temperature sensor. This is a ±1% thermistor that is 10 kΩ at 25°C.

It has a unique 0.6mm x 3mm cylindrical head encapsulated in a polyimide tube for applications where embedding the thermistor is required. It has 38 AWG nickel bifilar leads, which provide isolation from metal housing.

Dissipation Constant is ~0.2 mW / °C in still air.
Thermal Time Constant is ~200 msec in stirred liquid.

It is ideal for optical or thin surfaces and small laser packages. A complete Resistance vs. Temperature chart is included in the datasheet. It is sold in packs of 5.

Free, effective, and responsive technical support is available to simplify integration of Wavelength products into your OEM design. Standard product can be easily modified to meet your application requirements.

Wavelength Temperature Controllers include stable bias current sources of 10 µA and 100 µA. The following selection guide shows where the thermistor signal is within range of the controller inputs.

TCS605 5 kΩ -50 to -2°C -20 to +33 °C
TCS610 10 kΩ -45 to +13°C -8 to +50 °C
TCS10K5 10 kΩ -45 to +13°C -8 to +50 °C
TCS620 20 kΩ -35 to +28°C +6 to +69 °C
TCS650 50 kΩ -18 to +49°C +25 to +92 °C
TCS651 100 kΩ -6 to +64°C +41 to +114 °C
