Evaluation PCB for HTC Series Temperature Controllers

Temperature Sensors supported by this Temperature Controller
RoHS Compliant RoHS Compliant RoHS Compliant
Can be used with:
HTC1500-62 1.5 A Temperature Controller
HTC3000-62 3 A Temperature Controller
HTC4000-62 4 A Temperature Controller
Evaluation PCB for HTC Series Temperature Controllers
Quantity 1 2 - 9 10-24
Prices $ 150.00 $ 139.00 OEM Contact Factory
To order use part number: HTCEVALPCB
Prices are in US dollars.
Request a quote from factory or distributorRequest Quote
Add to Cart
Sometimes discounted stock is available Discount Stock
Technical detail about product Datasheet
Use the HTCEVALPCB Evaluation Board to rapidly prototype a complete temperature control system using the HTC1500-62, HTC3000-62, or HTC4000-62 Temperature Controllers. The HTCHTSK is included.

Onboard switches, connectors, and trimpots make configuration and operation simple. The HTC Temperature Controller is not included.

DVM cable ready test points monitor the setpoint and actual temperature. There is a main power switch with LED indicator. Another switch enables or disables output current. Power and load connections, inputs and monitors are on a terminal strip. A 2.5 mm jack is compatible with the power supplies: PWRPAK-5V (up to 8 A), PWRPAK-7V (up to 2.8 A), PWRPAK-9V (up to 3 A), or PWRPAK-12V (up to 2.5 A). DIP switches select current range, unipolar or bipolar operation, onboard or remote setpoint, and sensor bias currents. Onboard trimpots set proportional gain and setpoint.

Free, effective, and responsive technical support is available to simplify integration of Wavelength products into your OEM design. Standard product can be easily modified to meet your application requirements.
